Gearbox and driveline design, analysis and optimisation

MASTA is a complete suite of CAE software for the design, simulation & analysis of driveline systems from concept through to manufacture.

Overview

Design driveline systems

Design gearbox and driveline systems from scratch or imported concepts.

Analyse and Optimise

Run and generate reports on a wide variety of areas including NVH, system deflection, durability and FE



Watch the video - 3:10

Introduction to MASTA CAE software

MASTA Benefits

Accurately and rapidly design transmission systems from scratch or imported concepts.

Comprehensively understand the life of a mechanical part over the customer duty cycle.

Identify potential failure modes early in the product development cycle.

Rapidly predict key performance characteristics at the design stage.

Easily explore changes in transmission layout, component selection and/or design, materials and manufacturing processes in the convenience of a virtual environment.

Perform full system simulations for any transmission or driveline configuration.

Incorporate manufacturing simulation at the design stage to reduce process development time & cost.

MASTA’s unique and modern architecture written from the ground up in C# makes it a significantly more stable comparative solution for current and future operating systems.

Core Features

Design entire transmission and driveline systems using a comprehensive selection of components and design databases.

Gear tooth geometry optimisation.

Durability analysis for gears, bearings, shafts & splines.

System Deflection Analysis & Optimisation.

System NVH analysis & optimisation.

Loaded Tooth Contact Analysis.

Shaft Fatigue & Stress Analysis.

Shift Performance & Quality.

System Dynamics.

Gear Cutter Design and Manufacturing Process Simulation.

Housing & Shaft Deflection.

Gear Scuffing Analysis.

Drivetrain Simulation.

Planetary Load Sharing.

Isight interface for multi-parameter global optimisation.

Trusted and actively used by…

150

Blue Chip Companies

30

Global 500 Companies

10

USA Fortune Companies

“MASTA has been continuously used  in the design and application of engineering projects since its purchase and has proven itself to be highly usable and stable. It has been an imperative tool in the product development cycle and has allowed significant reductions in our analysis time with clear benefits to the business.”

SAIC Motor Technical Centre, UKPrincipal Engineer

“MASTA has greatly improved our gearcase design and analysis capabilities, and of all the decisions I’ve made over the 40 years working for Joy Global, half of that in gearcase design, picking MASTA CAE software is without doubt the best one!”

Joy Global: Underground Mining, USADesign Engineer

MASTA was an essential tool that helped achieve the goals we wished out of the designs in a relatively short period of time.

Hyosung Corporation, KoreaGeneral Manager
